Konica Minolta DryPro Sigma Printer

High-Resolution Digital Radiography Printing System
This next-generation dry film imager is engineered for high-precision diagnostic output in space-constrained medical environments. Utilizing advanced thermal imaging technology, it delivers high-density grayscale hardcopies across multiple modalitiesincluding CR, DR, CT, and MRIwithout the need for wet chemicals or darkroom processing.

1. Image Quality & Precision
Resolution: High-spatial resolution of 320 dpi (12.6 pixels/mm), ensuring crisp anatomical detail and smooth grayscale transitions.
Gradation: Supports 12-bit (4,096 levels) to 14-bit (16,384 levels) processing for superior diagnostic depth.
Consistency: Integrated automatic calibration (AIQC) maintains consistent density (D(max)) and image quality across every sheet.

2. Performance & Workflow
Throughput: Capable of producing up to 45 films per hour (for large 14 × 17" format), with higher rates for smaller sizes.
Rapid Start: Delivers the first print in as little as 50 seconds, significantly reducing patient wait times in high-traffic clinics.
Multi-Format Support: Versatile tray system accommodates the most common medical film sizes:8 × 10 inch (20 × 25 cm)10 × 12 inch (25 × 30 cm)14 × 17 inch (35 × 43 cm)

3. Connectivity & Integration
Network Protocol: Native DICOM 3.0 support for seamless "plug-and-play" integration with PACS, RIS, and hospital networks.
Interface: Standard 10/100/1000 Base-T Ethernet (RJ-45) for high-speed data transfer.

4. Design & Sustainability
Form Factor: Featuring an ultra-compact footprint, it is designed for tabletop use or installation in mobile medical vans and small control rooms.
Environmental Impact: * Dry Technology: 100% chemical-free operation; no liquid waste or disposal costs.
Acoustics: Engineered for ultra-low noise levels, maintaining a quiet clinical environment.
Energy Management: Features a Smart Sleep Mode that reduces power consumption during idle periods.
Technical Summary

Feature | Specification
Print Technology
Direct Thermal (Dry, Daylight Load)
Spatial Resolution: 320 dpi
First Print Time: 50 Seconds
Connectivity: DICOM 3.0 / Ethernet
Operating Noise
Ultra-Low / Quiet Mode
Power Management
Smart Sleep / Eco-Efficiency
